24V DALI Constant Voltage LED Driver, 40W 1.6A
ORION-DALI-40/24V
£44.40 Inc. VAT
Key Features
- 24V
- Up to 40 Watts
- DALI Dimmable LED Driver
- IP20
- 3 Year Warranty
Pay by card, American Express, PayPal, Apple Pay or Google Pay
Delivery & Returns
- Free UK DeliveryOrders over £75
- Next Day DeliveryFrom £8.95
- Returns14 Day Policy
Product Overview
Technical Specifications:
- Easy terminal access
- Rated 40w - 1.6Amp Max
- Dimensions: 137mm × 81.5mm × 31mm (L×W×H)
- Dimming modes : DALI
- Three Year Guarantee
Our range of DALI constant voltage LED drivers comply with the DALI standard protocol IEC 62386.
DALI (Digital Addressable Lighting Interface) is an International Standard for the control of electronic ballasts, transformers, LED's, emergency lights and exit signs in an easy to manage digital lighting control system.
Ideal for large projects, DALI is all in one solution for controlling low voltage lighting.
all products should be installed by a technically competent person in accordance with BS7671 and all other local regulations.
Product Specification
| Output | - |
| Output Voltage | 24V |
| Output Current | Up to 1.67 |
| Rated Power | Up to 40 Watts |
| Dimming Mode | Non Dimmable |
| Input | - |
| Input Voltage Range | 100 - 240 VAC |
| Input Frequency | - |
| Power Factor | >0.95 |
| Environment | - |
| Ingress Protection | IP20 |
| Min. Operating Temperature | -20°C |
| Max. Operating Temperature | 50°C |
| Protection | - |
| Overload Protection | - |
| Short Circuit Protection | No |
| Over Voltage Protection | No |
| Guarantee | 3 Years |
| Control Signal - Input | DALI |
| Dimmable | Yes |
| Dimming Type | DALI |
| Power Factor (A) | 0.95 |
| Application Environment | Indoor |
| Body Material | Plastic |
| Ingress Protection (IP) | 20 |
| Interior or Exterior Use | Interior |
| Input Current Type (A) | AC |
| Input Voltage Min. - Max (V) | 240-240V |
| Body Colour | White |
| Product Weight (g) | 220 |
| Constant Voltage / Constant Current | CV |
| Output Current Max. (A) | 1.67 |
| Output Current Type | DC |
| Output Voltage Min. - Max. (V) | 24-24V |
| Battery Included | No |
| Over Current Protection | No |
| Over Temperature Protection | No |
| Dimming Range Min. - Max (%) | 0.1-100% |
| Operating Temperature Min. - Max. (°C) | -20℃ to 50℃ |
| Brand | Tagra |
| Family Name | Orion |
| Rated Power (W) | 40 |
| Wattage (W) | 40 |
| Warranty (Years) | 3 |
| Product Height (mm) | 137 |
| Depth (mm) | 31 |
| Width (mm) | 82 |
| Dimensions LxWxH (mm) | 31x82x137 |
