Mains Powered 4 Zone Precision Touch 2.4GHz Wireless DMX RGB Wall Plate, White
PSCONN-MPRGBWALL-V2
£42.00 Inc. VAT
Key Features
- 100-240V AC
- Precision RGB Colour Control
- DMX 512 Compatible
- Control Up to 4 Zones
- 2.4GHz Wireless
Pay by card, American Express, PayPal, Apple Pay or Google Pay
Delivery & Returns
- Free UK DeliveryOrders over £75
- Next Day DeliveryFrom £8.95
- Returns14 Day Policy
Product Overview
Designed for a sleek wall mounted finish, this versatile controller can be used for both Wireless 2.4GHz control and as a DMX Master using the DMX512 Protocol making it compatible with Common DMX Decoders. This RGB Controller has 12 built in DMX channels ready for hard wiring into a DMX decoder.
When used for RF wireless control, Up to 4 zones can be controlled with multile receivers in each zone. Featuring an ultra sensitive touch control panel for precision control to your lighting installation.
100-240 VAC input with a White glass finish.
All complete with a piece of mind 5 year guarantee.
Product Features:
- Touch panel 4 zone RGB DMX512 master, can also be used as 4 zone RGB RF remote.
- DMX signal output which complies to the DMX512 protocol, compatible with DMX Decoders
- When used as an RF remote, each zone can remote control multiple RF 2.4GHz LED Receivers.
- Ultra sensitive high strength glass touch panel with touch color slide in the middle and backlit for operation in the dark.
- Smooth and accurate color adjustment by touching the color slide.
- Touch keys with LED indicator.
Videos
Product Specification
| Control Distance No Obstruction (m) | 30 |
| Number of Zones | 4 |
| Remote Included | No |
| Application Environment | Indoor |
| Body Material | Glass |
| Ingress Protection (IP) | 20 |
| Interior or Exterior Use | Interior |
| Mounting Type | WALL |
| Input Current Max. (A) | 0.1 |
| Input Current Type (A) | DC |
| Input Voltage Min. - Max (V) | 12-24V |
| Body Colour | White |
| Product Weight (g) | 230 |
| Number of Control Channels | 3 |
| Output Voltage Min. - Max. (V) | 100-240V |
| Battery Included | No |
| Operating Temperature Min. - Max. (°C) | 30℃ to 55℃ |
| Brand | Tagra |
| Product Height (mm) | 86 |
| Depth (mm) | 86 |
| Width (mm) | 12 |
| Dimensions LxWxH (mm) | 86x12x86 |
| Warranty (Years) | 5 |
