Tagra | IP65 | 24V | Essential | Horizontal Bend LED Neon Flex | 10x15mm | 8.0W p/m | 3000K | 50 Metres

Specifications:

• Voltage - 24v
• Dimensions - 15mm x 10mm
• LED Type - SMD2835 in Epistar Chip
• Number Of LEDs - 72 Per Metre
• Cut Points - Every 12.5cm
• Max Load - 12m
• LED Distance - 8.33mm
• Power - 5.31W Per Metre
• Lumens - 273 Per Metre
• CRI - >80
• Jacket Type: Dome
• Splashproof - subject to correct installation.
• Max Bend Radius - 2cm

Now available in a 50 metre reel, LED Neon Flex Mini is a new compact version of our Neon Flex tube lighting, at only 15 x 10mm its small size and light weight it is ideal for slimline perfect for single use display applications indoors and outdoors.

It's durable splashproof body allows for installations both in and outdoors where light water exposure may occur.

As the name suggests, it is highly flexible and can be bent to a minimum radius of 2 cm, and can be cut easily to your desired lengths. Maximum linear run at any time before voltage drop occurs is 10 metres.

Neon Flex can be dimmed via mains dimming, DALI, DMX or RF controllers.

Please Note: We are not able to offer refunds on cut lengths of Neon Flex Mini, only for full 50m reels. Our 50 metre reels of Neon Flex are supplied in a continuous 50 metre length.

For a working Neon Flex Mini installation you will need:

• Neon Flex Mini LED
• 1 x Neon Flex Mini Power Cable
• 1 x Neon Flex Mini Connector Pin
• 1 x Neon Flex Mini End Cap
• 1 x 24 volt power supply

Heat shrink tube is also highly recommended to seal both the endcap and power cable in order to maintain the splashproof rating.

All our neon flex comes with a 1 year guarantee on indoor and a 6 month guarantee outdoor installations.

Dimming Compatibility

• Compatible with dimmers using standard control protocols including DMX, Dali, 0-10V, PWM.
• Compatible with smarthome dimmers including those from Lutron, Loxone, Rayco, Control 4, Lightwave, Wizz, Casambi, Crestron.

Driver Requirements:
1 metre > 6w
2 metre > 12w
3 metre > 18w
4 metre > 24w
5 metre > 30w
6 metre > 36w
7 metre > 42w
8 metre > 48w
9 metre > 54w
Up to 12 metre – 80w

A 24v LED Transformer is required to power our Neon Flex.

All products should be installed by a technically competent person in accordance with BS7671 and all other local regulations.
