Smart 5-in-1 Wifi and 2.4GHz Wireless Controller, 6A per Channel, 12V-48V

Technical Specifications:

• Input voltage: 12-48VDC
• Input current: 30.5A
• Output voltage: 5 x (12-48)VDC
• Output type: Constant voltage
• Output current:
  • 6A per channel @ 12/24V
  • 4A per channel @ 36/48V
• Dimming range: 0 -100%
• Wireless control distance: 30 metres unobstructed
• Dimming gray scale: 4096 (2^12) levels
• IP Rating: IP20
• Operating Temperature: -30°C to +55°C
• Warranty: 5 Years

Features:

• Choice of PMW frequency: 500Hz, 2000Hz, 8000Hz or 16000Hz (when in single colour LED mode)
• Built in push dimming compatibility
• Compatible with Tuya Smart App
• Voice Controllable through Amazon ECHO

Introducing the 5-in-1 Wi-Fi and 2.4GHz Wireless LED Controller, a versatile lighting control solution designed for commercial and larger scale installs. This controller accommodates a wide spectrum of 12-48V LED strip lights including single colour, CCT tuneable, RGB, RGBW and RGB+CCT tuneable LED lights.

With support for input voltages ranging from DC12-48V and up to 6A per channel, it's a robust controller and seamlessly integrates into various large commercial LED lighting setups by being able to handle more amperage, higher voltages, and therefore, longer runs of LEDs compared to other more domestically focussed LED controllers on the market.

Applications include offices, retail and hospitality settings as well as larger high end residential projects.

Experience comprehensive control capabilities through the Tuya smart app , allowing precise adjustments for colour settings, brightness levels, delays, timers, scene configurations, and even music synchronization.

Moreover, this controller can be voice-controlled when integrated with Amazon Echo and for added convenience, can be paired with an optional RF 2.4GHz remote control. The controller's versatility ensures seamless compatibility with most modern LED lighting installations.

It can also function as a Wi-Fi to RF converter, enabling simultaneous control of multiple RF LED controllers through the Tuya app.

When in single colour mode, choose from selectable PWM frequencies of 500Hz, 2000Hz, 8000Hz, or 16000Hz to fine-tune your lighting experience. Additionally, you can adjust the light on/off and fade times, with a minimum setting of 3 seconds.

With its advanced capabilities, the Smart 5-in-1 Wi-Fi and 2.4GHz Wireless LED Controller enable the creation of a customized and responsive lighting experience in commercial settings and larger, more demanding LED lighting installations.
